Stainless Steel Arched Fireplace Doors for Large Arched Fireplace (72 x 29 1/2) - Project #20384

Customer Comments: Hi Greg This fireplace is huge! The opening is exactly 6 feet across. 29 1/2" on each side and A fraction under 36" at the center. I would love something with stainless steel trim, glass doors that open and screen doors inside if possible some type of vent on the bottom would be awesome but I’m not sure if that’s necessary? I look forward to seeing some of your ideas. Thanks so much

Our Comments: Not sure if you want a stainless steel finish, or if you want the doors made from stainless steel in a black finish. I have created mockups showing both. If you wish to burn fires with the doors closed, you will need ceramic glass, which requires each pane to be fully frame as in Option #3

Tempered vs Ceramic Glass: Tempered glass can handle sustained temperatures up to about 450F without breaking from heat. Ceramic glass can handle temperatures up to about 1450F. If you wish to burn fires with the doors closed, we highly recommend upgrading to ceramic glass.

Fireplace Opening: 72" W x 36" H (Center) x 29 1/2" H (Sides)

Before

Before:

Arched Stainless Steel Doors

Stainless Steel

Option #1: Hearth Creations Stainless Steel Arched Fireplace Door in Satin Stainless with Clear Glass and Gate Mesh Backup Doors.

Stainless Steel

Option #2: Hearth Creations Stainless Steel Arched Fireplace Door in Matte Black with Clear Glass and Gate Mesh Backup Doors.

Stainless Steel

Option #3: Hearth Creations Stainless Steel Arched Fireplace Door in Matte Black with Framed Ceramic Glass and Gate Mesh Backup Doors.

Arched Wrought Iron Door

Wrought iron is the most heavy duty material for fireplace doors and highly recommended for large bifolding doors. These can also be made with fullview ceramic glass panes, unlike the stainless steel doors that require fully framed panels.

Wrought Iron

Option #4: Hand Forged Wrought Iron Arched Fireplace Door in Burnished Black with Fullview Ceramic Glass and Gate Mesh Backup Doors.

Wrought Iron

Option #4B: Hand Forged Wrought Iron Arched Fireplace Door in Burnished Black with Fullview Ceramic Glass and Gate Mesh Backup Doors. Made with wider frame to accommodate production without a template.

Template Instructions

Template

Template Instructions:

1. Tape a piece of heavy plastic sheeting to the fireplace.
2. Make sure the bottom edge is perfectly straight and even with the hearth.
3. Make sure it is taped tightly enough to remove any wrinkles.
4. Trace the shape of the opening with a fine tip marker including the mortar joints.
5. If you make a mistake, make a note and point to the correct part of the line that is to be used.
6. Measure the bottom width, top width, left height, center height and right height and mark them on the template.
7. Mark the template as shown with “Outside Looking In, Fireplace Treatments, Customer: Love.
8. Email me a picture of the template and leave it in place so I can see how it was made and approve it.
9. Once I approve it, you can take it down, cut off the tape and mail it to the address that I provide.

Other Pictures

Fig #1 - Closeup

Fig #2 - Room Setting

Fig #3 - Room Setting

Glass Door Mesh Options

If you are planning on burning anything in your fireplace, you need to have mesh behind the glass so you can burn a fire with the doors open. You can chooe between gate mesh backup doors and sliding mesh curtains. Functionally, gate mesh performs the best as the wire has smaller holes that sparks cannot get through. Aesthetically, mesh curtains may be preferred because they do not have a vertical center frame that obstructs the view of the fire. When you are not using the fire or you want a complete unobstructed view, they do not stick out like gate mesh doors when they are opened.

We are showing these options on a flat steel bifold door with a satin brass overlay and gray glass.

No Mesh

Gate Mesh Backup Doors

Mesh Curtains
